MPO/MTP Adapter Cable

DIMI Fiber manufactures MPO/MTP adapter cables for high-density fiber connections between MPO/MTP interfaces and specified optical equipment or distribution systems. Configurations are available for OS2, OM3, OM4, and OM5 fiber, with 8, 12, 16, and 24 fibers, pinned or non-pinned connectors, Type A/B/C polarity, standard or custom lengths, and PVC, LSZH, or OFNP jackets.

MPO Polarity Conversion Cable
The MPO Polarity Conversion Cable is a factory-terminated fiber assembly designed to correct fiber-position or Tx/Rx polarity mismatches in high-density MPO/MTP cabling systems. It provides a...

view more
MPO Female To Male Adapter Cable
The MPO Female To Male Adapter Cable is a factory-terminated multi-fiber assembly with an MPO female connector on one end and an MPO male connector on the other. The female end uses alignment...

view more
MTP To LC Adapter Cable
The MTP To LC Adapter Cable is a factory-terminated fiber optic assembly that connects a high-density MTP/MPO interface to multiple LC duplex interfaces. It is designed for structured cabling...

view more
MPO To FC Adapter Cable
The MPO To FC Adapter Cable is a factory-terminated fiber optic assembly that connects an MPO/MTP interface to individual FC interfaces. It is designed for data centers, telecom networks, optical...

view more
MPO To SC Adapter Cable
MPO to SC Adapter Cable is a factory-terminated fiber optic fanout assembly that connects a high-density MPO/MTP® interface to individual SC optical interfaces. The assembly can be specified by...

view more
MPO To LC Adapter Cable
MPO to LC Adapter Cable is a factory-terminated multi-fiber cable assembly that connects a high-density MPO/MTP interface to individual LC duplex ports. It is used to transition between...

view more

MPO/MTP Adapter Cable Types

DIMI Fiber supplies MPO/MTP adapter cable assemblies for different connector interfaces, fiber configurations, and polarity requirements.

MPO to MPO Adapter Cable

Pre-terminated MPO cable assemblies for direct connections between compatible MPO interfaces. Available with specified fiber counts, pin configurations, polarity, and cable lengths.

MTP to MTP Adapter Cable

MTP-based multifiber assemblies for high-density connections between compatible MTP interfaces. Pinned or non-pinned configurations are selected according to the mating connectors.

MPO/MTP to LC Adapter Cable

Converts a multifiber MPO/MTP interface to LC connections for equipment, distribution systems, and specified breakout configurations. Fiber count, polarity, connector type, and cable length are configured according to the application.

MPO/MTP to SC Adapter Cable

Provides an MPO/MTP-to-SC interface configuration for systems requiring a multifiber connection on one side and SC connectivity on the other.

MPO Polarity Conversion Cable

Designed for specified MPO fiber mapping and polarity conversion requirements. Type A, Type B, or Type C configurations are available according to the existing link architecture.

Custom MPO/MTP Adapter Cable

Custom assemblies can be produced with specified fiber type, fiber count, connector combination, pin configuration, polarity, fiber mapping, cable length, and jacket. Existing cables, drawings, BOMs, or connector part numbers can be provided for configuration verification.

MPO/MTP Adapter Cable Configurations

The cable assembly can be specified according to the connector interface, fiber configuration, and installation requirements.

Parameter	Available Options
Connector	MPO / MTP
Connector Pin	Pinned / Non-pinned
Fiber Count	8 / 12 / 16 / 24 fibers
Fiber Type	OS2 / OM3 / OM4 / OM5
Polarity	Type A / Type B / Type C
Cable Length	Standard lengths / Custom length
Jacket	PVC / LSZH / OFNP
Operating Temperature	-20°C to +70°C
Compliance	IEC 61754-7 / TIA-604-5 / Telcordia GR-1435-CORE, where applicable
Material Requirements	RoHS / REACH; applicable flame-retardant requirements

Specifications are confirmed against the selected connector, fiber, and cable configuration before production.

MPO/MTP Interface Compatibility

MPO/MTP adapter cables are configured to match the connector interface, pin configuration, fiber count, fiber type, polarity, and fiber mapping of the connected equipment or existing cable.
Typical configurations include:

01/

MPO/MTP to MPO/MTP: Connects compatible MPO/MTP interfaces on fiber cassettes, trunk cables, patch panels, transceivers, and other optical equipment.

02/

MPO/MTP to LC: Connects a multifiber MPO/MTP interface with equipment or distribution components using LC connections.

03/

MPO/MTP to SC: Connects an MPO/MTP interface with specified SC-based fiber equipment or distribution components.

04/

Pinned to Non-Pinned: The connector pin configuration is selected according to the mating connector.

05/

Type A / B / C Polarity: Polarity and fiber mapping are configured according to the required fiber-to-fiber arrangement.

06/

OS2 / OM3 / OM4 / OM5: Fiber type is selected to match the existing optical infrastructure and connected equipment.

Connector and Pin Configuration

MPO/MTP adapter cables require the correct mating connector configuration. Pinned and non-pinned versions are selected according to the connector on the mating side.

Pinned / Male: Incorporates alignment pins for positioning against a compatible non-pinned connector.

Non-pinned / Female: Uses the mating connector's alignment pins for connector alignment.

MPO / MTP Interface: Multifiber connector configuration for high-density connections.

MPO/MTP to LC or SC: Available for specified interface conversion and breakout configurations.

For replacement or system-matching orders, the existing connector part number or cable sample can be used to verify the required pin configuration.

Polarity and Fiber Mapping

Polarity determines how individual fibers are mapped between the two ends of an MPO/MTP assembly. The selected polarity must match the equipment and link architecture.

Polarity	Fiber Mapping
Type A	Straight-through mapping
Type B	Reversed mapping
Type C	Pair-wise reversed mapping

DIMI Fiber can manufacture assemblies according to specified polarity and fiber mapping requirements. For unclear configurations, provide the existing cable, system drawing, BOM, or fiber mapping information for verification before production.

Applications

MPO/MTP adapter cables are used in:

Data center fiber infrastructure

High-density fiber distribution systems

Telecom infrastructure

Enterprise network equipment

High-performance computing environments

Network expansion and reconfiguration

Fiber cable replacement and maintenance

Suitability depends on the complete optical channel, including fiber type, transceiver, polarity, connector configuration, and channel loss.

Quality & Test Documentation

DIMI Fiber verifies MPO/MTP adapter cables against the specified connector, fiber, and polarity configuration before shipment.

Quality control can include:

Connector Geometry: 3D interferometric inspection of radius of curvature, apex offset, and fiber protrusion.

End-Face Condition: Digital microscopic inspection of connector end faces according to applicable IEC 61300-3-35 criteria.

Optical Testing: Insertion loss, return loss, and optical continuity testing according to the specified configuration.

Fiber Mapping: Verification of fiber-to-fiber continuity and polarity where required.

Test Records: Individual optical test data can be supplied with the order where specified.

Testing requirements are confirmed according to the selected fiber type, connector configuration, and polarity rather than applying a single specification across all MPO/MTP adapter cables.

Custom MPO/MTP Adapter Cable Manufacturing

DIMI Fiber supports custom adapter cable production for OEM projects, network deployment, and replacement requirements.
Customization can include:

Fiber type: OS2 / OM3 / OM4 / OM5
Fiber count: 8 / 12 / 16 / 24
MPO or MTP connector
Pinned or non-pinned configuration
Type A, B, or C polarity
Specified fiber mapping
MPO/MTP to LC or SC configurations
Cable length
PVC, LSZH, or OFNP jacket
Heavy-duty or armored breakout construction where applicable
Private labeling
Custom barcoding
Kitted or bulk packaging

Customers can provide a drawing, existing cable, BOM, connector part number, equipment interface, or sample as the production reference.

FAQ

Q: What is an MPO/MTP adapter cable?

A: An MPO/MTP adapter cable is a pre-terminated fiber assembly used to connect specified MPO/MTP interfaces or to connect an MPO/MTP multifiber interface with another connector interface such as LC or SC.

Q: What is the difference between pinned and non-pinned MPO/MTP connectors?

A: Pinned connectors include alignment pins, while non-pinned connectors are designed to mate with pinned connectors. The required configuration depends on the connector on the mating side.

Q: Which MPO polarity should I choose?

A: Type A provides straight-through fiber mapping, Type B reverses the fiber order, and Type C reverses fibers in pairs. The correct selection depends on the fiber mapping and equipment architecture of the installation.

Q: Can you match an existing MPO/MTP cable?

A: Yes. An existing cable, drawing, BOM, connector part number, or equipment interface can be used as a reference for confirming connector, fiber count, pin configuration, and polarity.

Q: Can you provide optical test data?

A: Optical testing can include insertion loss, return loss, continuity, and fiber mapping. Individual test records can be supplied with the order where specified.

Q: Can you manufacture custom MPO/MTP adapter cables?

A: Yes. Custom production is available for fiber type, fiber count, connector combination, pin configuration, polarity, fiber mapping, cable length, jacket, labeling, and packaging requirements.
