MPO/MTP Single Mode Fiber Cable

Single-mode MPO/MTP fiber cable assemblies for high-density optical interconnection, extended transmission distances, and parallel optical connectivity. Available in Base-8 and Base-12 configurations, with 8-, 12-, 16-, and 24-fiber options, APC connector configurations, Type A/B/C polarity, and standard, low-loss, and ultra-low-loss performance grades.

Low Loss OS2 MPO Fiber Cable
The Low Loss OS2 MPO Fiber Cable is a factory-terminated single-mode fiber assembly using OS2 9/125 μm fiber and MPO/MTP-compatible multi-fiber connectors, with the connector and polarity...

view more
MPO To LC Single Mode Fiber Cable
The MPO To LC Single Mode Fiber Cable is a factory-terminated OS2 breakout assembly that converts a multi-fiber MPO/MTP interface into individual LC duplex connections.

view more
MPO Single Mode Patch Cord
The MPO Single Mode Patch Cord is a factory-terminated multi-fiber optical assembly using OS2 single-mode fiber and MPO/MTP-compatible connector interfaces at both ends.

view more
MPO Single Mode Trunk Cable
The MPO Single Mode Trunk Cable is a factory-terminated multi-fiber optical assembly using OS2 single-mode fiber and MPO/MTP-compatible connectors at both ends.

view more
OS2 MTP Single Mode Fiber Cable
The OS2 MTP Single Mode Fiber Cable is a factory-terminated MTP/MPO trunk assembly using OS2 9/125 μm single-mode fiber, with multi-fiber connectors at both ends for direct connection between...

view more
OS2 MPO Single Mode Fiber Cable
The OS2 MPO Single Mode Fiber Cable is a factory-terminated multi-fiber optical assembly for high-density single-mode fiber connectivity in data center, telecom and other structured optical...

view more

Single Mode Fiber Cable Specification Options

Our MPO/MTP single-mode cables use OS2 single-mode fiber for optical links where transmission distance, insertion loss, and link-budget control are critical.

Specification	Options
Fiber Type	OS2 Single Mode
Fiber Grade	G.652.D / G.657.A1 / G.657.A2
Fiber Count	8 / 12 / 16 / 24 fibers
Base Configuration	Base-8 / Base-12
Operating Wavelength	1310 / 1550 nm
WDM Range	1270–1330 nm options according to application
Polarity	Type A / Type B / Type C
Operating Temperature	-20°C to +70°C

G.657.A1 and G.657.A2 bend-insensitive fibers are available for high-density routing where reduced bend radius and cable-space constraints need to be considered.

Standard, Low-Loss & Ultra-Low-Loss Performance

MPO/MTP single-mode assemblies are available in different insertion-loss grades to accommodate different optical link budgets.

Performance Grade	Maximum Insertion Loss
Standard	≤0.70 dB
Low Loss	≤0.35 dB
Ultra-Low Loss (ULL)	≤0.25 dB

The required loss grade should be selected according to the transceiver specification, number of mated connections, transmission distance, and available optical power budget. ULL configurations are available for systems where connector loss has a tighter impact on the overall link budget.

Base-8 & Base-12 MPO/MTP Configurations

Base-8 and Base-12 architectures support different parallel-fiber transmission and equipment interfaces.

Base-8 Single Mode MPO

Base-8 configurations are available for optical systems using 8-fiber parallel interfaces and are suitable for high-density architectures associated with newer high-speed optical connectivity.
Available configurations include:

8-fiber MPO/MTP assemblies
Male or female connectors
Type A / Type B / Type C polarity
APC connector configurations
Standard, low-loss, and ULL performance
Custom cable lengths and constructions

Base-12 Single Mode MPO

Base-12 configurations provide 12-fiber connectivity for established MPO/MTP cabling architectures and high-density backbone applications.
Available configurations include:

12-fiber MPO/MTP assemblies
24-fiber assemblies using two 12-fiber interfaces
Male or female connectors
Type A / Type B / Type C polarity
APC configurations
Standard and low-loss options

MPO/MTP Connector & Polarity Compatibility

Single-mode MPO/MTP connections require correct connector gender, fiber mapping, polarity, and end-face configuration.

Type A: Straight-through fiber mapping

Type B: Reversed fiber mapping

Type C: Pair-flipped fiber mapping

Male: Guide pins installed

Female: Guide pins omitted

APC: 8° angled physical contact configuration for applicable single-mode interfaces

For replacement cables or project orders, equipment model, interface specification, existing cable sample, drawing, or fiber mapping can be provided for configuration verification.

MPO/MTP Single Mode Cable Construction

Different cable constructions are available for installation space, routing, and mechanical requirements.

Cable Construction	Typical Requirement
Round Cable	General structured cabling and equipment routing
Flat Ribbon	High-density parallel fiber arrangement
Micro Cable	Reduced cable diameter and limited routing space

Jacket options include LSZH, OFNP, OFNR, and PVC, depending on installation requirements and applicable local codes.

Single Mode vs. Multimode MPO/MTP

The primary distinction between this category and MPO/MTP multimode fiber cables is the optical fiber and transmission architecture.

Item	MPO/MTP Single Mode	MPO/MTP Multimode
Fiber	OS2	OM3 / OM4 / OM5
Core Size	9/125 μm	50/125 μm
Typical Wavelength	1310 / 1550 nm	850 nm
Transmission Reach	Long-distance	Shorter-distance
Typical Use	Backbone, DCI, telecom, inter-building	Data center short-reach links
High-Speed Interface	Single-mode DR/FR and related systems	Multimode SR systems

Select single mode when the equipment specifies OS2 fiber, the link requires extended reach, or the available optical budget requires single mode transmission characteristics.

MPO/MTP Single Mode Cable Applications

Data Center Interconnect

High-density OS2 MPO/MTP assemblies for connections between data halls, network distribution areas, and longer-reach optical links.

400G / 800G Optical Connectivity

Base-8 and other parallel-fiber configurations for compatible high-speed optical transceiver architectures.

Telecom & Carrier Networks

MPO/MTP connectivity for single-mode backbone and high-density fiber distribution systems.

WDM & Parallel Optical Systems

Single-mode assemblies supporting optical systems using 1310 nm, 1550 nm, or applicable WDM wavelength ranges.

Inter-Building Fiber Links

Pre-terminated single-mode connectivity for links between buildings, equipment rooms, and network distribution points.

Optical Testing & Quality Verification

Each MPO/MTP single-mode cable assembly can be verified against the specified optical and physical configuration before shipment.

Insertion Loss & Return Loss: Tested at specified wavelengths, including 1310 nm and 1550 nm.

3D Interferometric Inspection: Checks fiber height, radius of curvature, apex offset, and ferrule geometry.

End-Face Inspection: Checks for scratches, pits, contamination, and other end-face defects.

Polarity Verification: Confirms Type A, B, or C fiber mapping.

Final Configuration Check: Verifies fiber count, connector type, gender, polarity, cable construction, length, and labeling.

Batch-level test documentation can be provided according to project and order requirements.

Our Advantages in MPO/MTP Cable Manufacturing

50,000+ m² Production Facilities

Over 50,000 m² of production space supports dedicated areas for fiber optic cable assembly, connector manufacturing, hardware fabrication, and final testing.

ISO-Certified Quality Management

ISO 9001:2015, ISO 14001, and TL 9000 certifications provide a documented quality management framework for production and quality control.

50+ Engineers & Technicians

More than 50 engineers and technicians support product development, process improvement, prototyping, and customized fiber optic solutions.

Flexible Production Capacity

Annual capacity of over 2 million connector assemblies, 500,000 meters of fiber optic cable, 100,000 distribution boxes, and 200,000 hardware accessories supports both volume production and custom orders.

FAQ

Q: What fiber is used in MPO/MTP single-mode cables?

A: The standard fiber type is OS2 single-mode, with G.652.D, G.657.A1, and G.657.A2 options available according to the application.

Q: Is MPO/MTP single-mode normally APC?

A: APC is commonly specified for single-mode MPO/MTP applications where the optical interface requires angled physical contact and higher return-loss performance. The connector polish must match the equipment interface.

Q: What is a Base-8 MPO cable?

A: A Base-8 MPO cable uses an 8-fiber interface architecture and is used with optical systems designed around eight-fiber parallel connectivity.

Q: What is the difference between low-loss and ultra-low-loss MPO cables?

A: Low-loss configurations provide insertion loss up to the specified low-loss limit, while ULL configurations target a tighter insertion-loss value, such as ≤0.25 dB. The appropriate grade depends on the system link budget.

Q: Can G.657.A2 fiber be used in MPO/MTP cables?

A: Yes. G.657.A2 bend-insensitive single-mode fiber can be specified where high-density routing or tighter bend management is required.

Q: Can you provide custom MPO/MTP single-mode cables?

A: Yes. Fiber count, base configuration, polarity, connector gender, cable length, loss grade, cable construction, jacket, labeling, and packaging can be specified for project requirements.
